ELX200-12SP
ELX200-12SP
A compact 12-inch powered subwoofer with 1,200 W of Class-D and QuickSmart DSP.
Features
Add the bottom and keep the load light. The ELX200-12SP drives an EV-engineered 12-inch woofer with 1,200 W of Class-D power to reach up to 129 dB SPL, with an adjustable low-pass and system-match crossovers to lock it to your tops. A 15 mm plywood cabinet keeps it compact at 22.3 kg shipping, and an M20 pole mount stands the tops right on top. Mobile rig, small club, corporate AV. Roll it in and feel it.
- Feel the low end — EV-engineered 12-inch woofer and 1,200 W Class-D up to 129 dB SPL.
- Match your tops — adjustable low-pass at 80, 100, 120, or 150 Hz plus system crossovers.
- Move it solo — compact 15 mm plywood cabinet at 22.3 kg shipping, two-handle design.
- Build a stack fast — integrated M20 pole mount carries the full-range tops.
- Tune it on the fly — QuickSmart DSP with three presets and five user-storable settings.
Specifications
Power & Amplification
- Amplifier Watt Peak
1200
- Operating Voltage / Power
100 - 240 V~, 50 - 60 Hz, 1.2 0.6 A
Construction & Materials
- Enclosure
15 mm plywood with EVCoat
Dimensions & Weight
- Shipping Weight
22.3 kg (49.2 lb)
Identification
- Series / Family
ELX200
- Material Number
F.01U.351.458
