EOL 8001 End-of-line supervision module
EOL 8001 End-of-line supervision module
An end-of-line supervision module that watches a loudspeaker line for shorts and opens.
Know the speaker line works before you need it. The EOL 8001 sits at the end of a loudspeaker line and, paired with the EOL master built into every PROMATRIX 6000 controller and router or PROMATRIX 8000 amplifier, monitors that line for short and open circuits. A status LED confirms the install on the spot. For continuous business-music sites and voice-alarm chains, it turns line integrity from an assumption into something the system reports.
Key features
Catch faults early
monitors the loudspeaker line for short and open circuits.
Works with the system
pairs with the EOL master in PROMATRIX 6000 and 8000.
Verify on site
status LED confirms the installation at a glance.
Disappears in the room
15 x 78 x 60 mm, 30 g, fits at the line end.
Built for compliance
EN 54-16 certified for voice-alarm applications.
Scale to the system
wire limits support up to 60 modules on PROMATRIX 6000 lines, 30 on PROMATRIX 8000.
Features
Know the speaker line works before you need it. The EOL 8001 sits at the end of a loudspeaker line and, paired with the EOL master built into every PROMATRIX 6000 controller and router or PROMATRIX 8000 amplifier, monitors that line for short and open circuits. A status LED confirms the install on the spot. For continuous business-music sites and voice-alarm chains, it turns line integrity from an assumption into something the system reports.
- Catch faults early — monitors the loudspeaker line for short and open circuits.
- Works with the system — pairs with the EOL master in PROMATRIX 6000 and 8000.
- Verify on site — status LED confirms the installation at a glance.
- Disappears in the room — 15 x 78 x 60 mm, 30 g, fits at the line end.
- Built for compliance — EN 54-16 certified for voice-alarm applications.
Specifications
Protection & Environmental
- Ambient Temperature
EN 50581
- Certifications
EN 54-16
Dimensions & Weight
- Net weight
30 g
- Dimensions (H x W x D) (mm)
15 mm x 78 mm x 60 mm
Identification
- Series / Family
EOL
- Material Number
F.01U.140.823
